WCRE Series Wet Concrete Recycling Equipment

WCRE fully automatic waste wet concrete recycling equipment can decompose and recycle all the waste residue and wastewater generated by the mixing plant every day. The recycled sand, gravel and slurry water can be used in concrete production to achieve circular application, saving a lot of raw materials and greatly reducing the development of natural resources.

Product Parameters

Parameter	Unit	WCRE60C（Mixing pool type）	WCRE60B（Mixing tank type）
Installed power	kW	100	120
Floor space (length x width)	m	22*13	17*14
Processing capability	m³/h	60
Applicable enterprises	/	Annual production of 600,000 cubic meters of concrete, 40-80 tank trucks

Product Details

Product Overview

Product Characteristics

1. Low carbon and environmentally friendly, zero sewage discharge.

2. Highly intelligent, one-button start, automatic switching to working modes, unattended.

3. Good sand and gravel separation effect, full utilization of slurry water.

4. The equipment occupies a small area and has strong site adaptability.

Introduction To Original Function Modules
1. Cyclone separation system Secondary separation of particles larger than 0.075mm. mud content of discharge material is less than 1%, efficiency> 90%.
2. Spiral roller screen The spiral roller screen has its own lifting function, and does not require a belt conveyor. The discharge height fully meets the needs of the forklift to shovel more materials at a time, avoiding frequent shoveling and reducing energy consumption.
3. Sewage sil The large sewage silo on the ground is equipped with an agitator, which is started intermittently to quickly mix the recycled water evenly. The sewage silo has the function of automatic sewage discharge and cleaning, reducing the cost of manual cleaning.
